Floor-to-Ceiling TV Mount Telescopic Tension Pole for 37″ – 75″ LCD/LED Screens

  • Use only 2 fingers to slide up/down big whiteboard / touch screen up to 40cm (15.7″)
  • Weight of the interactive whiteboard / touch screen balanced by the internal spring force (23-40Kg / 50.6-88lbs)
  • Fit most 37″ to 55″ Touch Screens, most 80″-120″ Whiteboard, and most 65″-75″ Smart TVs (*see compatibility notes)
  • Support Weight Range: 23-40Kg / 50.6-88lbs, and VESA 200×200, 300×300, 400×200, 400×300, 400×400, 600×400, 800×400
  • Only 3 main parts, easy to assemble and wall mount


SKU: DRD-FCM63M Category:


Floor-to-ceiling TV mount are becoming a popular choice for open-plan offices and sitting-room. The DRD-FCM63M is the most attractive and versatile floor ceiling mount. It features attractive aluminium poles, cable management in the poles, and a shelf for laptop/game players/media players. The top pole is telescopic, which makes the FCM63M floor-to-ceiling TV mount suitable for ceiling with height from 2.1 to 2.7 meters (82.7″-106.3″). The TV mount bracket has a load capacity of max. 30 Kg and is suitable for most 37″-75″ LED/LCD screens (*See notes on compatibility). The TV bracket can move up /down the middle pole, height range 87-162cm (34.3″-63.8″). There is also a shelf for laptop / PS4 / Xbox / Blu-ray / DVD player, the max load capacity is 5Kg. The shelf can also move up/down the lower pole, height rage 5-85cm (2″-33.4″). The FCM63M floor ceiling TV mounts can be screw-down to the floor for permanent installation, or can be weigh-down for temporary use.

fcm63m weigh-down screw-down floor mount

fcm63m floor ceiling tv mount compatibility

Notes on Compatibility To be 100% sure that this floor ceiling TV mount is compatible, make sure your TV/screen satisfy the following:

  1. Weight ≤ 30Kg
  2. There are 4 threaded mounting holes at the back of the TV/screen, see image below
  3. The horizontal distances between the mounting holes ≤ 600mm / 23.6″, see image below
  4. The top row of mounting holes are above the horizontal middle line of the TV , see image below

FCM63M floor ceiling tv mount tension pole features sizes dimensions diagram FCM63M floor ceiling
