Icon Desktop Units

An all new desktop unit available in black or white, the Icon Desktop unit has a distinctive modern design suited to any new office.

    • Integral USB A + C charger (Fitted with all Icon units)

    • 2 x UK sockets

    • Individual power switches

    • Resettable thermal fuses

    • Keystone cutouts- can be populated with data/multimedia/blank

Icon datasheet

£48.50

Description

ICON desk power and data units symbolise the most stylish and flexible offering available
today with so many features built in, both sockets have a master switch with a blue ‘on’
indicator, to meet BS6396 re-settable 3.15A thermal fuses are used instead of normal fuses
thus lowering the cost of ownership.
Like the innovative PD COMBO ADVANCE 80mm power grommet, the ICON uses a universal
keystone fixture allowing hot swapping of data or media such as Cat 6, Cat 6A, USB A or C
and HDMI coupler modules. In fact, there are 40 different combinations that the 5 coupler
modules can be employed. We list, from our experience, what we believe would be the most
popular but there is no limit to the flexibility.
The ICON could also be used to house a terminated keystone module as part of a structured
cabling system, a true end to end solution, patch panel to the end user at the desk, or it
could be left with fillers installed to be used anytime in the future if an upgrade is needed.
The ICON also uses smart USB chargers, Smart charging means the charger sends the
appropriate power intelligently to the device, the A&C USB charger has a total output of both
A&C of 18W max for example:
USB-A & USB-C QC 3.0, 2V/5A, 5V/3A & 9V/2A and complies with BC1.2 and Apple Protocol
USB-C PD, 2V/5A, 5V/3A & 9V/2A, complies with BC1.2, PD2.0, QC3.0 and Apple Protocols
An all-new desk clamp is used to fix the ICON in place, and although mundane we have used
FSE responsibly sourced card for boxing with biodegradable wrap to protect the ICON in
transport.
