OE PRO PIXEL 100W Dual USB-C In-Desk Charger
Bring dual USB-C charging neatly into your desk. The OE PRO PIXEL combines two USB-C ports with a built-in 100W power supply.
- 80mm round cut-out for desks or furniture panels.
- Black or white fascia to suit your workspace.
- Replaceable USB module accessible from the front.
Choose your colour and starter lead below. Select a 1–5m lead, or “No starter lead required” only if you already have a compatible power connection. Lead surcharges shown in the options are ex VAT.
In stock at OE Electrics: typical lead time is 2–3 working days. Contact us to confirm availability for project quantities or a required delivery date.
Price range: £111.40 through £125.15 ex VAT Price range: £133.68 through £150.18 inc VAT
Description
OE PRO PIXEL 100W Dual USB-C In-Desk Charger
The OE PRO PIXEL 100W dual USB-C in-desk charger puts two charging ports within easy reach, neatly integrated into your desk or furniture. Its flush-fitting design uses a standard 80mm round cut-out, with a built-in 100W power supply and a choice of black or white fascia.
USB-C charging built into your workspace
Planning an office desk, shared workstation or meeting table? Built-in USB-C charging gives users a convenient connection at the work surface. PRO PIXEL can be fitted horizontally into a desktop or vertically into a furniture panel, giving you flexibility when specifying new furniture or upgrading an existing installation.
The front-accessible, replaceable USB-C module makes future servicing more straightforward, while the power supply stays integrated within the unit. Choose your fascia colour and the starter lead length that suits your installation, then check device power requirements and fitting dimensions before ordering.
Key features at a glance
- Fits a standard 80mm diameter cut-out.
- Suitable for horizontal desk mounting or vertical panel installation.
- The USB module can be replaced from the front; the power supply remains built into the unit.
- High-strength, flame-retardant polycarbonate body.
- Available with black or white fascias; the body and power cable are black.
Download the OE PRO PIXEL 100W datasheet (PDF)
Choose your setup in 3 steps
- Choose your colour: black or white fascia. The body and power cable are black.
- Choose a starter lead: select 1m, 2m, 3m, 4m or 5m to suit the distance to your power connection. Only choose no starter lead if you already have a compatible connection.
- Check your selection: review the displayed price, set your quantity and add to basket.
Unsure which lead you need? Ask us to check compatibility before ordering. For a project or a required delivery date, contact us for current availability and lead time.
Technical specifications
| Manufacturer | OE Electrics |
|---|---|
| USB ports | 2 x USB-C |
| Power supply | Integrated 100W PSU |
| Mounting cut-out | 80mm diameter |
| Installation | Horizontal desk or vertical furniture panel |
| Fascia colours | Black or white |
| Body | High-strength, flame-retardant polycarbonate |
| Starter lead options | No starter lead, or 1m, 2m, 3m, 4m or 5m |
Frequently asked questions
Select a question to read the answer.
Will it fit my desk?
The unit uses an 80mm diameter cut-out. Check the datasheet and the dimension drawing in the image gallery for clearance before cutting or modifying furniture.
Does each USB-C port provide 100W?
The 100W rating describes the built-in power supply; it should not be read as 100W from each port simultaneously. Contact us to confirm the output available for your intended devices, particularly when using both ports.
Is a starter lead included?
A starter lead is supplied only when you select a lead length. The “No starter lead required” option is for installations with an existing compatible power connection.
Can the USB charging module be replaced?
Yes. The dual USB-C TUF module can be replaced from the front. The power supply is built into the unit.
Need help with your installation?
Call 0800 852 1010 or email info@dataroomdirect.com for help with connections, quantities or delivery requirements.
Compare other OE Electrics in-desk power and USB charging units.
Additional information
| Manufacturer | OE Electrics |
|---|---|
| USB Configuration | 2 x USB-C |
| Power Supply | Integrated 100W PSU |
| Cut-out | 80mm diameter |
| Mounting | In-desk, In-panel |
| Colour | Black, White |
| Starter Lead | No starter lead required (+£0.00), 1m (+£7.50), 2m (+£8.10), 3m (+£9.20), 4m (+£13.75), 5m (+£11.75) |
